SURGIPRO
Introducer Sheaths

Sino-Sheath Radial Introducer Set

The SINO-SHEATH introducer set (Polymer and Spring types, 4F–9F) for percutaneous vascular access — including radial access — prior to inserting angiographic, balloon or similar catheters.

Get a quote All products
Sino-Sheath Radial Introducer SetSino-Sheath

Overview

SINO-SHEATH is an introducer system for smooth, atraumatic insertion of instruments between the dilator and sheath, used in endovascular procedures requiring safe, controlled vascular access. The kit includes an introducer, a dilator, a mini-guidewire (including a spring guidewire), a metal injection needle with a plastic cannula, an advancer with a protective valve, and a scalpel for access preparation. Available 4F–9F in lengths 6–25 cm.

Key features

  • Complete kit: introducer, dilator, mini-guidewire, needle, advancer, scalpel
  • Smooth, atraumatic insertion between dilator and sheath
  • Mini-guidewire types: hair-wire, polymer or spring
  • Advancer with a protective valve
  • Minimises the risk of tissue damage during access

Clinical applications

  • Percutaneous vascular access (radial / femoral)
  • Introduction of catheters and other instruments
  • Endovascular procedures

Intended use

Sino-Sheath is a high-tech introducer system for smooth, atraumatic insertion of medical instruments between the dilator and sheath. It is used in endovascular procedures requiring safe, controlled vascular access (including radial access) for the insertion of catheters and other instruments.

Specifications

Type
Radial / femoral introducer set
French sizes
4F / 5F / 6F / 7F / 8F / 9F
Lengths
6 – 25 cm
Mini guidewire
0.018" / 0.021" / 0.025" / 0.035", 45 cm
Needle / syringe
20 Ga / 18 Ga; 3 cc
Coating
Available with or without hydrophilic

Manufactured by TIBTEXNIKA LLC (Uzbekistan). Distributed in Pakistan by SURGIPRO as the authorized representative & importer. Specifications are indicative — always refer to the manufacturer's Instructions for Use (IFU). For use by qualified healthcare professionals only.

Diagram

Sino-Sheath introducer set — sheath, dilator, mini-guidewire, injection needle, advancer and scalpel.
Sino-Sheath introducer set — sheath, dilator, mini-guidewire, injection needle, advancer and scalpel.

Click a diagram to open it full size.

Technical parameters

Sheath sizes
4F · 5F · 6F · 7F · 8F · 9F (femoral / radial)
Sheath lengths
6 / 7 / 8 / 10 / 12 / 13 / 14 / 25 cm
Kit contents
Introducer, dilator, mini-guidewire (incl. spring), injection needle with plastic cannula, advancer with protective valve, scalpel
Needle / syringe
Catheter IV 20 Ga (21/20 Ga needle) or 18 Ga (18 Ga needle); 3 cc syringe

Sizes & ordering

Mini-guidewire options

TypeTip & wire lengthTip diameter
H (hair wire)Curved tip — 45, 70 cm0.018" (C)
P (polymer coating)Curved 45 cm · Straight 45 cm0.018" / 0.025" / 0.035" (S, C)
S (spring)Curved 45 cm · Straight 45 cm · J-shaped 45, 70 cm0.021" (S,C) · 0.025" (S) · 0.035" (J)

Ordering — radial type 0.021"

French (Fr)Length (cm)
678101213142125
4SS-R-021-04-060SS-R-021-04-070SS-R-021-04-080SS-R-021-04-100SS-R-021-04-120SS-R-021-04-130SS-R-021-04-140SS-R-021-04-210SS-R-021-04-250
5SS-R-021-05-060SS-R-021-05-070SS-R-021-05-080SS-R-021-05-100SS-R-021-05-120SS-R-021-05-130SS-R-021-05-140SS-R-021-05-210SS-R-021-05-250
6SS-R-021-06-060SS-R-021-06-070SS-R-021-06-080SS-R-021-06-100SS-R-021-06-120SS-R-021-06-130SS-R-021-06-140SS-R-021-06-210SS-R-021-06-250
7SS-R-021-07-060SS-R-021-07-070SS-R-021-07-080SS-R-021-07-100SS-R-021-07-120SS-R-021-07-130SS-R-021-07-140SS-R-021-07-210SS-R-021-07-250
8SS-R-021-08-060SS-R-021-08-070SS-R-021-08-080SS-R-021-08-100SS-R-021-08-120SS-R-021-08-130SS-R-021-08-140SS-R-021-08-210SS-R-021-08-250
9SS-R-021-09-060SS-R-021-09-070SS-R-021-09-080SS-R-021-09-100SS-R-021-09-120SS-R-021-09-130SS-R-021-09-140SS-R-021-09-210SS-R-021-09-250

Order-code format: SS-R-021-[Fr]-[length]; length encoded in mm (060 = 6 cm).

Ordering — radial type 0.025"

French (Fr)Length (cm)
678101213142125
4SS-R-025-04-060SS-R-025-04-070SS-R-025-04-080SS-R-025-04-100SS-R-025-04-120SS-R-025-04-130SS-R-025-04-140SS-R-025-04-210SS-R-025-04-250
5SS-R-025-05-060SS-R-025-05-070SS-R-025-05-080SS-R-025-05-100SS-R-025-05-120SS-R-025-05-130SS-R-025-05-140SS-R-025-05-210SS-R-025-05-250
6SS-R-025-06-060SS-R-025-06-070SS-R-025-06-080SS-R-025-06-100SS-R-025-06-120SS-R-025-06-130SS-R-025-06-140SS-R-025-06-210SS-R-025-06-250
7SS-R-025-07-060SS-R-025-07-070SS-R-025-07-080SS-R-025-07-100SS-R-025-07-120SS-R-025-07-130SS-R-025-07-140SS-R-025-07-210SS-R-025-07-250
8SS-R-025-08-060SS-R-025-08-070SS-R-025-08-080SS-R-025-08-100SS-R-025-08-120SS-R-025-08-130SS-R-025-08-140SS-R-025-08-210SS-R-025-08-250
9SS-R-025-09-060SS-R-025-09-070SS-R-025-09-080SS-R-025-09-100SS-R-025-09-120SS-R-025-09-130SS-R-025-09-140SS-R-025-09-210SS-R-025-09-250

Order-code format: SS-R-025-[Fr]-[length]; length encoded in mm (060 = 6 cm).

Exact dimensional figures, full pressure-compliance charts and order codes are confirmed against the manufacturer's current Instructions for Use (IFU) and catalogue. Request the full datasheet.

Quality & certification

Manufactured under GMP technology by TIBTEXNIKA LLC with internationally certified quality-management systems.

  • ISO 13485:2016
  • ISO 9001:2015
  • Production Licence
  • CE Certificate
Manufacturer
TIBTEXNIKA LLC, Uzbekistan
Category
Introducer Sheaths
Product family
Sino-Sheath
Quality system
GMP · ISO 13485:2016
Regulatory
DRAP — Medical Devices Rules, 2017
Documentation
IFU, datasheet, Free Sale & registration — on request
Intended user
Qualified healthcare professionals only
